TECHNICAL DATA: 1) Maximum working pressure [ SGP - PC(SZ) ] = 6 Bar 2) Maximum working pressure [ SGP - PC(WB) ] = 8 Bar 3) Maximum working pressure [ SGP - PC(DW) ] = 8 Bar 4) Liquid Temp range [ SGP - PC(SZ) ] = 0�C ~ 45�C 5) Liquid Temp range [ SGP - PC(WB) ] = 0�C ~ 55�C 6) Liquid Temp range [ SGP - PC(DW) ] = 0�C ~ 55�C 7) Amient Temp : 0�C ~ 40�C 8) Strating pressure : factory steeing 1.5 bar 9) Protection class : IP55
PERFORMANCE DATA: 1) Capacity =2 m3/hr to 12 m3/hr 2)Head = 9m3/hr to 32 m3/hr 3) Power = 0.25 KW to 1.1 KW 4) Voltage = 220 V 5) Frequency = 50 Hz 6) Phase = 3 phase 7)RPM = 2900r/min
