TECHNICAL DATA: 1) Maximum working pressure : 6 bar 2) Maximum Liquid temp : 45�C 3) Maximum suction head : 8 mtr 4) Special Mechanical seal are available upon request 5) This pump can be used at full head without overloading motor 6) T.E.F.C , 7) continious duty 8) Insulation Class : F or B 9) Protection Class: IP55 and IP54 10) Ambient temp range : -15�C ~ 40�C 11) Altitude <= 1000m 12) Single phase : 220V, 50HZ, 2900 rpm 13) With over load protector in single phase motor 14) Three phase : 380V, 50Hz, 2900rpm 15) Over load protector in 3 phase is available on request
PERFORMANCE DATA: 1) Capacity = 0.6 m3/hr to 5.4 m3/hr 2)Head = 12 mtr to 45 mtr 3) Power = 0.37 Kw to 0.90 kw 4) Voltage = 220V , 380V 5) Frequency = 50 Hz 6) Phase = Single phase & Three phase 7)RPM = 2900r/min
